Denon AVR-X2800

Specifications

Multichannel Surround

DTS HD Master, DTS:X, DTS:X Pro

o, o,

DTS Neo:X, DTS Neural:X

-,

DTS Virtual:X

IMAX Enhanced

Dolby TrueHD,

Dolby Atmos,

Dolby Atmos Height Virtualization,

Dolby Atmos Music

o,

o,

o,

Dolby ProLogic Ilz, Dolby Surround

-,

Auro 3D

360 Reality Audio/MPEG H

Multichannel Stereo

Max Number of Processing (Preamp) Channels

7.1

Sound enhancements

Mono Block Power Amp Construction

Discrete Power Amplifier

D.D.S.C. HD Digital

Pure Direct

Gold Plated RCA Terminals

Clock Jitter Reducer

Alpha Processing

Audyssey

MultEQ XT

Audyssey Dynamic EQ, Dynamic Volume

o,

Audyssey LFC

Dirac Live Upgradability

Compressed Audio Restorer

Network

Media Server

HEOS Wireless Multi-Room Technology

Alexa/Google Voice Assistant/Apple HomePod

o, o,

Lossy Formats: MP3, WMA, AAC

o, o,

Lossless Formats: FLAC, ALAC, WAV

o, o,

Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit)

o, o,

DSD Audio Streaming

(2.8/5.6MHz)

AirPlay 2

TuneIn

Spotify Connect

Roon Tested

HEOS App Control

Compatible with Remote APP for Smart Phones

Denon 2016 AVR Remote

Ethernet Ports

Wi-Fi

Bluetooth

HDMI

HDMI Inputs: Back, Front

6,

HDCP2.3 support

HDMI Outputs: Main, Zone

2 /

HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB

o,

HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR

, o, o, o,

ALLM (Auto Low Latency Mode) Pass-Through for Gaming

Variable Refresh Rate, Quick Flame Transport, Quick Media Switching

o, o,

3D Signal Pass-through

8K Signal Pass-Through, Scaling, GUI Overlay

o, o,

DSD Audio Capability

Audio Return Channel (ARC), Enhanced ARC

o,

Auto LipSync

Multi-Room / CI

Multi-Room Zones

2

Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog

(2ch), (2ch), o,

Zone Audio Output: Speaker, Pre-Out

o,

Zone HDMI Output from HDMI Source

IP Control, RS232 Control, Web Control, App Control

o, /o,

Remote In / Out

o,

DC Trigger Output

HDMI Diagnostics

Others

Auto Speaker Setup by Microphone

Audyssey MultEQ XT

Front Display

1-Line FLD

GUI Languages

3

Setup Assistant

Quick Select Plus, Quick Select

o,

Variable Crossover

Optimized Bass Redirection

Bass Sync

ECO Mode

Auto Power Off

Sleep Timer

Inputs/Outputs

HDMI In / Out

6, 2

Multi-room Video Out: Video / HDMI

-,

Analog In, Out

4,

Phono (MM) In

Digital In: Optical / Coaxial

2, 1

Multi-room Out: Analog / Digital

1,

Multichannel Preout

(0.2)

Subwoofer Out

2

Speaker Terminal: Gold Plated Screw / Regular Screw

-,

Number of Speaker Terminals

7

Speaker A / B

Assignable

Bi-amp Drive

Assignable

Multi-Room Speaker Terminal

Assignable

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

-, -, -, -,

USB Audio / Made for iPod / Made for iPhone

o, -,

AM/FM Tuner

Specifications

Number of Poweramps

7

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)

95W

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)

125W

Power Output (6 ohm, 1 kHz, 10% 1ch Drive)

185W

General

Metal Front Panel

System Remote Control

RC-1253

Pre-programmed / Learnable / LCD Display

-, -,

Power Consumption in W

500

Power Consumption No-Sound (ECO On / Off) in W

35W/75W

Standby Consumption in W

0.1

CEC Standby Consumption in W

0.5

Network Standby Consumption in W

Less than 2.0

Maximum Dimensions
Antenna:Horizontal: (W x D x H) in inches
Antenna:Vertical: (W x D x H) in inches)
【w/o Antenna: (W x D x H) in inches】

17.1 x 13.4 x 6.6
( 17.1 x 13.4 x 9.3 )
【 17.1 x 13.0 x 6.6 】

Weight in LBS

21.0

Weight in lbs (Packaging)

25.4
